We Offer Solar Energy Solutions in all Pakistan to reduce your Electricity bills
Ut tellus dolor, dapibus eget, elementum ifend cursus eleifend, elit. Aenea ifen dn tor wisi Aliquam er at volutpat. Dui ac tui end cursus eleifendrpis.
Phone No:
+92 333 9564378
Email Address:
info@essenceengineeringpvt.com
Essence Engineering Pvt Limited offers consultancy and installation services on solar agricultural tube wells all over Pakistan
We design solar tube wells for irrigation, drinking water supply schemes, and drainage pumping systems. Our team designs water pumping systems from 1HP to 50HP. Since inception, we have designed and installed solar tube wells in Punjab, KPK, and Merge districts FATA.
By using solar tube wells, farmer can reduce their electricity bills and diesel expenses. They can convert their diesel engines to electric motors for the utilization of solar energy.
We offer the following services before and after the design and installation of solar tube wells.
Our team collects the following data during the survey and assessment of the solar tube well.
We design the solar tube well on existing data collected from site or mentioned by the customers. The solar system is to be designed in such a way as to ensure a minimum of 6 hours of irrigation. The solar panel VFD, submersible/monoblack machine, manual tracker, and other accessories are the main parts of our solar tube wells.
The cost of our solar tube wells depends upon the HP. The bigger the HP the more will be the cost. HP depends upon water table depth and the discharge required by the former.
Our installation starts with:
We provide complete training for formers/ operators to run the VFD. A manual of safety measures and operations is hand over the customer.
We provide one year after sales services. Which includes:
Note: All these warranties are subject to the manufacturer’s warranty, terms, and conditions.
We provide free consultation on solar tube wells, which includes suggestions and recommendations about the horsepower (HP) of the motors and head of pumps(feet/meter).
Our design team has the expertise in designing tube wells for more than 16 years. We provide ideal design and economical estimates to full the requirement of the customer.
We conduct electrical resistivity surveys for the establishment of new tube wells to ensure underground availability of water
Our team of solar tube well experts ensures the installation and commissioning of solar tube wells within 3 to 5 days.
We provide training to farmers and operators for the smooth running of solar tube wells. We also provide safety measures to avoid any electric hazard.
Essence Engineering Pvt Limited provides one-year after-sales services for solar tube wells to ensure good pressure of water through out the year.
If you have a question for us, see if we’ve answered it below. You’ll find answers
to the questions people ask us about the most.
Pipe diameter(inches) = Specific Discharge(LPH)
1" = 5500 LPH
1.5" = 8500
2" = 12500
2.5" = 18500
3" = 28500
4" = 48500
6" = 96500
The discharge and head are inversely proportion.
1 cusec (28.32 LPS) of water can irrigate 100 acres through out the year
To calculate the horsepower of a solar tube well there are two main factors:
The horsepower of the tube well is directly proportional to the discharge and also directly proportional to the suction head. The formula for estimated horsepower is:
HP= {Discharge x Head} / { Motor Efficiency / Pump Efficiency }
Where
Discharge = LPS
Head = Meter
Motor Efficiency = 75% to 85%
Pump Efficiency = 55% to 65%
